KIWA Horizontal Machining Centers

KIWA Horizontal Machining CentersHorizontal machining centers from KIWA are engineered for efficient production, reliable accuracy, and pallet-based workflow optimization. A fifth-generation, family-owned CNC machine tool builder, KIWA machines are designed to maximize spindle utilization and reduce non-cutting time. Their emphasis on palletization, simplicity, and reliability allows manufacturers to improve productivity without unnecessary complexity.

KIWA’s feature-rich machines incorporate their exclusive in-the-field expandable tool and pallet technology into 5-axis and HMCs. Cost-effective pricing with options for future expandability makes KIWA a smart choice for job shops. KIWA machines also feature a small footprint, making them ideal for shops with limited space.

KIWA machines reduce downtime, improve throughput, and maintain consistent quality in both high-volume and high-mix environments. Their straightforward mechanical design and automation readiness make KIWA a strong fit for manufacturers focused on productivity and scalability.

Whether deployed in a single-machine cell or expanded into a palletized production system, KIWA horizontal machining centers deliver dependable performance and long-term value.

  • KH-4100kai

    KIWA KH-4100kai – high-performance horizontal machining center with full rotary B-axis installable in a space equal to a vertical machining center

    • X axis Travel 20.1″ (510 mm)KIWA KH-4100kai
    • Y axis Travel 20.1″ (510 mm)
    • Z axis Travel 20.1″ (510 mm)
    • 4th Axis Travel (Rotary Table): 0 to 360 degrees
    • Wide center trough in the machining area and a strong bed coolant wash
    • Pallet Load Capacity: 1100 lbs (500 kg)
    • 60 Tools
    • 15K RPM
    • FANUC 0i-MF Control
  • KH-4200kai

    KIWA KH-4200kai – high-performance horizontal machining center with full rotary B-axis installable in a space equal to a vertical machining center

    • X axis Travel 22″ (560 mm)KIWA KH-4200kai
    • Y axis Travel 26″ (660 mm)
    • Z axis Travel 22″ (560 mm)
    • 4th Axis Travel (Rotary Table): 0 to 360 degrees
    • Wide center trough in the machining area and a strong bed coolant wash
    • Pallet Load Capacity: 1100 lbs (500 kg)
    • 60 Tools
    • 15K RPM
    • FANUC 0i-MF Control
  • KH-4500kai

    KIWA KH-4500kai – high-performance horizontal machining center with one of the largest work envelopes in its class

    • X axis Travel 27.6″ (700 mm)
    • Y axis Travel 29.1″ (740 mm)
    • Z axis Travel 26.8″ (680 mm)
    • 4th Axis Travel (Rotary Table): 0 to 360 degrees
    • Pallet Load Capacity: 1100 lbs (500 kg)
    • 60 tools standard (40/80/120/240 opt)
    • Spindle Speed: 15000 RPM (12000 or a 20000 built-in)
    • FANUC 31iB Control
  • Triple H40 3-Axis

    Triple H40 3-Axis – high-performance horizontal machining center with a Column Traverse Design

    • X axis Travel 20.1″ 510 mm)KIWA Triple H40 3-Axis
    • Y axis Travel 20.1″ (510 mm)
    • Z axis Travel 15.7″ (400 mm)
    • Pallet Load Capacity: 2200 lbs (1000 kg)
    • 40 tools
    • Spindle Speed: 12000 RPM (opt)
    • FANUC 0iMF Control
  • Triple H40 5-Axis

    Triple H40 5-Axis – high-performance horizontal machining center with a Column Traverse Design

    • X axis Travel 20.1″ 510 mm)KIWA Triple H40 5 axis
    • Y axis Travel 20.1″ (510 mm)
    • Z axis Travel 15.7″ (400 mm)
    • 4th Axis Travel (Tilt Axis) -30 and + 120 degrees
    • 5th Axis Travel (Rotary Axis) 360 degrees
    • Pallet Load Capacity: 880 lbs (400 kg)
    • 40 tools
    • Spindle Speed: 12000 RPM (opt)
    • FANUC 0iMF Control

    The machine design will accommodate a variety of workpieces and factory automation equipment.  The 5 axis version allows for heavy parts to be machined on five sides.
