Swistek Swiss CNC Lathes
Swistek Swiss CNC Lathes are built with quality from the ground up and will help any manufacturer produce parts that they can be proud of, no matter if they’re machining small prototype runs of ten pieces or are producing millions of parts to be distributed around the world.
Swistek offers an extensive family of machine solutions including Swiss CNC lathes with Removable Guide Bushing (for shorter parts), Sliding Head Non Guide-Bush Type lathes, and Fixed Headstock CNC lathes that can handle diameters ranging from 2mm (.080″) – 60mm (2.375″) at an economical price without sacrificing quality. All Swistek machines come fully loaded with a FANUC control, revolving guide bushing, removable guide bushing for short parts (3 x Dia max), part catcher, part conveyor, bar feeder, chip conveyor, and chip cart.
-
AS20T
7-Axis – 20mm Mini-Turn/Mill Non-Guide Bush Type Sliding Headstock Lathe
The AS20T comes standard with a M70 Mitsubishi 7-Axis 64 Bit Controller, simultaneous sub-spindle, 4 live cross working tools, C-Axis on the Main and Sub-Spindle, part conveyor, chip conveyor and broken cut off sensor. This 7-axis Swiss screw machine is very economical and is capable of manufacturing easy-to-complex parts at a very competitive price. Non-Guide Bush Type machines are generally for manufacturing parts under 3.5 x Bar Diameter overall part length.
Standard features include:
- Non Guide-Bush Type Swiss
- Easy To Program
- 20mm Bar Capacity
- 7 Controllable Axis
- Simultaneous Subspindle
- C-Axis Main and Subspindle
- 4 Live Cross Tools
- Part Catcher
- Part Conveyor
- Chip Conveyor with Chip Carts
- Broken Cut-off Detection
- 3 stage Tower Light
- *Optional Live Face Tools on Main
- *Optional Live Face Tools on Sub
-
GT-25E/32E
Swiss Type Automatic Screw Machines
The GT series is designed especially for small and high volume precision parts with powerful processing capacity, stable quality, and superior accuracy. It is the best choice for manufacturers of high precision parts.
-
iB-269
Swiss Type Automatic Screw Machines
The iB-269 is a powerful machine that offers a fast traverse speed alongside high precision machining quality. Featuring a 9-axis layout, this machine is capable of performing operations faster and more efficiently with simultaneous working through the main and sub-spindle as well as over 20 slots for tooling.
-
RB20/RB20Y
7 Axis Swiss-Type CNC Screw Machine w/Removable Guide Bushing and Y-Axis Subspindle Tools
The Swistek RB20 (7-axis) and RB20Y (8-axis) HYBRID offers a sliding headstock Swiss-Type CNC Lathe with an optional Removable Guide Bushing that offers Precision, Reliability, Performance, Speed and Capability at a very economical price compared to the competition . The Use of NSK Bearings, Ball Screws and Super Precision Linear ways help to achieve optimal accuracy and repeatability on those tight tolerance parts.
Standard features include:
- 4 Position Back working (RB20), 8 Position Y axis Back working (RB20Y)
- 20mm Bar Capacity
- 7.480″ Main Spindle Stroke
- 7 Axis (RB20), 8 Axis (RB20Y)
- Independent Subspindle
- FANUC 32i-B Control
- HYBRID Removable Guide Bushing
- Rapid Traverse Rate 1,290ipm
- Synchronous Rotary Guide Bushing
- Up to 19 Live Tools (RB20), Up to 23 Live Tools (RB20Y)
- Up to 41 Tools Total (RB20), Up to 47 Tools Total (RB20Y)
- C-Axis Main and Subspindle
- 5HP Main/Sub Spindle
- Rotating Part Conveyor
- Chip Conveyor with Cart
- Huge Array of attachments
-
SV26-Y2 1-Inch Machine
Swiss Type Automatic Screw Machines
The Swistek SV26-Y2 is a beast of a Swiss screw machine that sports a 1-inch bar capacity with a FANUC 32i control. Featuring hydraulic clamping on the main and sub-spindle and room for up to 47 tools, this machine is ready for any part that you can throw at it.
-
SW50-Y2
Swiss Type Automatic Screw Machines
38mm Capacity with Guide Bushing, 2.00″ Capacity without Guide Bushing. The Swistek SW50-Y2 offers an 8-Axis sliding headstock Swiss Type Screw Machine with a Removable Guide Bushing that brings precision, reliability, performance, and speed at a very economical price compared to the competition.
Standard features include:
- 8 Position Y axis Back working
- 2.00″ Bar Capacity
- 12.00″ Main Spindle Stroke
- 8 Axis
- Independent Subspindle
- FANUC 32i-B Control
- HYBRID Removable Guide Bushing
- Rapid Traverse Rate 1,290ipm
- Synchronous Rotary Guide Bushing
- Up to 23 Live Tools
- Up to 47 Tools Total
- C-Axis Main and Subspindle
- 15HP Main/Sub Spindle
- Rotating Part Conveyor
- Chip Conveyor with Cart
- Huge Array of attachments
