Non-Contact Metrology System UltraSurf 5X is a high precision 5-Axis non-contact metrology system. All axes are made of the highest quality air bearings and linear motor technology available. A variety of probe options allow for sub-micron single and dual surface scanning of precision optical components. OptiPro's innovative software provides comprehensive contour analysis, coordinate control features and surface texture analysis for roughness and p-v waviness profiles. ASCII data export provides a seamless integration to standard optical fabrication platforms. The UltraSurf 5X has two different model configurations: The UltraSurf 5X 100, for measuring 100 mm sized optics and the UltraSurf 5X 200, for measuring 200 mm sized optics. UltraSurf 4X is the 4-axis version of the non-contact measurement system and also comes in the 100 and 200 models. The UltraSurf 4X is almost identical to the 5X, with the only difference being that the 4X has a manual Y-axis stage for alignment, not a computer-controlled Y-axis for measurement. UltraSurf 5X Tech Specs >>  UltraSurf 5X Brochure >> UltraSurf 4X Tech Specs >>  UltraSurf 4X Brochure >>  Watch UltraSurf In Action >>

Current Measurement Abilities Rotationally Symmetric Sphere, Hemisphere, Asphere, Ogive 4 total axes of movement, 1 during data collection 2-Dimensional X-Y B-Axis can move probe to keep normal 3 total axes of movement, 1 during data collection

Unlike any alternative, the UltraSurf is the only measurement system that can measure the thickness and quality of the both the inside and outside surfaces of unusually shaped optics or other parts without touching them.
