PRO Series Optical Production Equipment
OptiPro Systems has launched their new line of machines for low, medium, and high volume production of precision optics. The PRO Series Optical Production Equipment includes the PRO 80G or GTS (Grinder, Twin-Spindle as an option), PRO 80P (high speed spherical polisher), PRO 80UFF (UltraForm Finishing for aspheres) and the PRO Tower (vertical interferometer). With powerfully simple job-setups, exceptional ergonomics, highest quality machine components and robust spindles, the PRO 80 Series provides competitively priced machines built completely in the USA!
 |
High Precision Lens Generator: 5 to 80 mm Optics
The PRO 80G or GTS (Grinder, Twin-Spindle as an option) is capable of grinding spherical lenses in optimal cycle times with high precision. |
PRO 80G >> |
 |
High Speed Spherical Polisher: Up to 80 mm Optics
The PRO 80P is a high speed spherical lens polisher for workpieces up to 80 mm in diameter. Fast setups and cycle times are achieved with the PRO 80P, yielding high production of spherical optics.
|
PRO 80P >> |
|
|
UltraForm Finishing for Aspheres: 10-80 mm Optics
The PRO 80UFF utilizes OptiPro's patented sub-aperture polishing system called UltraForm Finishing (UFF). The PRO 80UFF can UltraForm Finish planos, spheres, and aspheres from 10-80 mm in diameter, with freeform fabrication as an optional add-on. |
PRO 80UFF >> |
|
|
Wavefront and Radius Measurement: Up to 300 mm Optics
The PRO Tower vertical interferometer is capable of measuring the wavefront and radius of optics that are up to 300 mm in diameter. It has a motorized stage with 1,000 mm of travel and is available with a CGH for asphere metrology. This robust platform is great for either fast in-process metrology or final metrology. |
PRO Tower >> | |
